Waste Oil Pyrolysis Purifier Special For Making Diesel 0086-15890067264

Payment Terms:	T/T
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean

Waste Oil Pyrolysis Purifier for diesel fuel,Pyrolysis Oil Equipment from waste tyre, Waste rubber pyrolysis equipment,

Waste Oil Pyrolysis Purifier for diesel,Pyrolysis Oil Equipment from wast e tyre , Waste rubber pyrolysis equipment, Waste Oil Pyrolysis Purifier Special For Making Diesel

Waste Oil Pyrolysis Device for making diesel fuel oil

2. Description:

good quality, high efficienty to refine fuel oil with waste plastic, rubber, tyre, etc. We can make special spec as per requests

Technical Detail:

• This is a batch process system.

• The waste tyres are fed into the reactor vessel and heated under controlled conditions of temperature and pressure.

• The process will bring about molecular restructuring of the rubber under the pyrolysis process as the result; furnace oil in gaseous form is produced along with other gases.

• These vaporized gases are passed through heat exchanges, where in the furnace oil is condensed into liquid form.

• During the process, carbon black and steel are also generated.

• The heat exchanger uses coolant water, as a condensing medium and this water is re-circulated through process.

• These systems can be operated 24/365.

3. Components for the whole line:

1, horizontal rotation cracking processor
2, sub-air package
3, condenser flue
4, fuel oil storage tanks
5, the oil-water separation tank
6, water-cooled cooling system
7, the water sealing
8, pressure, temperature, multi-point monitoring system
9, the central electronic control system
10, cooling system
11, gas heating system (exhaust gas treatment system)
12 powerful spray dust removal system (in line with international emission standards)
13, wastewater treatment system (Optional: oil burner waste water, water treatment systems to solve problems, achieve zero discharge of liquid waste)

model	GLRJ-5	GLRJ-8	GLRJ-10
Raw material	Waste rubbers/tyres/plastic	Waste rubbers/tyres/plastic	Waste rubbers/tyres/plastic
Door's model	Semi-open door	Semi-open door	Semi-open door
Structure Form	Horizontal type	Horizontal type	Horizontal type
Daily Handling capacity	5 tons	8 tons	10 tons
Material of reactor	Q245R thickness 14mm	Q245R thickness 14mm	Q245R thickness 14mm
Working pressure	Normal pressure	Normal pressure	Normal pressure
Main engine rotating speed	0.4R/min	0.4R/min	0.4R/min
Power	16 KW	20 KW	20 KW
Cooling Mode	Water	Water	Water
Consumption of Cooling water	0.2T/hour	0.3T/hour	0.4T/hour
Heating Mode	Direct	Direct	Direct
Installation	Main engine integral installation	Main engine integral installation	Main engine integral installation
Noise dB (A)	<=85	<=85	<=85
Machine dimension(mm)	D2200*L6000	D2600*L6000	D2600*L6600
Working Mode	Intermittent	Intermittent	Intermittent
Weight	28T	28T	28T

4.Occupying space: total (150m2)

1, pyrolysis processor                30m2
2,  dust handling system             5m2
3, the cooling system               70-75 m2
4, sub-air package                   1.5 m2
5, the oil-water separation tank, heavy tank, the water sealing  5 m2
6,  wastewater treatment system               5m2
